Hydraulic Coupling / Adapter
Gates Hydraulic Coupling / Adapter G25830-0404 is engineered to provide secure, leak-free connections in high-pressure hydraulic systems. This hydraulic adapter is built for durability, offering long-lasting performance in challenging environments. Designed for ease of installation, the hydraulic coupling reduces downtime and improves system efficiency. Resisting wear and tear, it guarantees reliable operation under tough conditions. Perfect for heavy-duty machinery, this hydraulic adapter ensures continuous, dependable performance in demanding applications. Trusted by professionals, it delivers secure connections and maximizes the productivity of hydraulic systems.
$15.94
Specifications
The patented "C" insert pre-assembled MegaCrimp coupling gives world-class, leak-proof performance. It is designed with a patented "C" insert attached to the ferrule that accommodates hose of different constructions and wall thicknesses. The insert's design ensures crimping forces are evenly distributed to form a concentric seal. The "C" insert simplifies inventory requirements since one MegaCrimp coupling size can accommodate various hose outside diameters, on both one- and two-wire braid hydraulic hose. Includes O-ring sealing in flare.
- Female British Standard Parallel Pipe O-Ring Swivel (MegaCrimp)
Weight
0.1500
Swivel:Yes
Thread Size:1/4-19
Seal Type:Mated Angle w/O-Ring
Inside Diameter:.25
Length:1.57
Seat Angle:30
Compatibility
Alternative Part Numbers
Dayco 101650
Dayco 116027
Dayco 153027
Aeroquip 1A4BF4
Goodyear 13105-0404
Goodyear 14105-0404
Goodyear B2-BPFX-0404
Goodyear T7-BPFX-0404
Goodyear T8-BPFX-0404
Goodyear UC-BPFX-0404
Hydraulink S01H-0404
Kurt Hydraulics F-BSPX-04-04
NAPA G25830-0404
Parker 19243-04-04
Parker 19243-4-4
Parker 1GU43-04-04
Parker 1GU43-4-4
Parker 1GUHY-4-4
Weatherhead 04E354
Weatherhead 04EE354
Weatherhead 04U354
Weatherhead 04Z354
Weatherhead 1GU43-4-4
Dayco 116027
Dayco 153027
Aeroquip 1A4BF4
Goodyear 13105-0404
Goodyear 14105-0404
Goodyear B2-BPFX-0404
Goodyear T7-BPFX-0404
Goodyear T8-BPFX-0404
Goodyear UC-BPFX-0404
Hydraulink S01H-0404
Kurt Hydraulics F-BSPX-04-04
NAPA G25830-0404
Parker 19243-04-04
Parker 19243-4-4
Parker 1GU43-04-04
Parker 1GU43-4-4
Parker 1GUHY-4-4
Weatherhead 04E354
Weatherhead 04EE354
Weatherhead 04U354
Weatherhead 04Z354
Weatherhead 1GU43-4-4
