Gates Corporation Hydraulic Coupling / Adapter Part No: G25230-0810
MegaCrimp
Gates Hydraulic Coupling / Adapter G25230-0810 provides a secure and durable connection for hydraulic systems, even under high-pressure conditions. This hydraulic adapter is designed for exceptional durability, reducing the need for frequent maintenance and preventing costly failures. The hydraulic coupling ensures leak-free performance, helping to maintain the integrity and efficiency of your hydraulic system. With simple installation, this hydraulic adapter integrates easily into existing setups, ensuring optimal functionality. Whether replacing or upgrading, this Gates hydraulic coupling guarantees reliable, long-term performance. Trust this adapter to improve productivity and boost system reliability in all hydraulic applications.
Specifications
The patented "C" insert pre-assembled MegaCrimp coupling gives world-class, leak-proof performance. It is designed with a patented "C" insert attached to the ferrule that accommodates hose of different constructions and wall thicknesses. The insert's design ensures crimping forces are evenly distributed to form a concentric seal. The "C" insert simplifies inventory requirements since one MegaCrimp coupling size can accommodate various hose outside diameters, on both one- and two-wire braid hydraulic hose. SAE J1453 O-ring Face Seal.
- Female Flat-Face O-Ring Swivel (MegaCrimp)
Gender:Female
Swivel:Yes
Thread Size:1-14
Seal Type:O-Ring
Inside Diameter:.5
Length:2.76
Swivel:Yes
Thread Size:1-14
Seal Type:O-Ring
Inside Diameter:.5
Length:2.76
Weight
0.4100
Compatibility
Alternative Part Numbers
- Aeroquip 1AA10FR8
- Caterpillar 124-2118
- Caterpillar 1JS43-10-8
- Dayco 108718
- Dayco 151718
- Goodyear 13700-0810
- Goodyear 14700-0810
- Goodyear B2-OFFX-0810
- Goodyear T8-OFFX-0810
- Goodyear UC-OFFX-0810
- Kurt Hydraulics FFX-08-10
- NAPA G25230-0810
- Parker 1JC43-10-08
- Parker 1JC43-10-8
- Parker 1JS43-10-08
- Parker 1JS43-10-8
- Parker 1JSHY-10-8
- Weatherhead 08EES70
- Weatherhead 08ES70
- Weatherhead 08US70
- Weatherhead 08ZS70
