Gates Corporation Hydraulic Coupling / Adapter Part No: G25175-0606
$25.85
MegaCrimp
Female JIC 37 Flare Swivel - 45 Bent Tube (MegaCrimp)
Specifications
The patented "C" insert pre-assembled MegaCrimp coupling gives world-class, leak-proof performance. It is designed with a patented "C" insert attached to the ferrule that accommodates hose of different constructions and wall thicknesses. The insert's design ensures crimping forces are evenly distributed to form a concentric seal. The "C" insert simplifies inventory requirements since one MegaCrimp coupling size can accommodate various hose outside diameters, on both one- and two-wire braid hydraulic hose.
Gender: Female
Swivel: Yes
Thread Size: 9/16-18
Seal Type: Mated Angle
Inside Diameter: .375
Length: 3.05
Drop Length: .43
Swivel: Yes
Thread Size: 9/16-18
Seal Type: Mated Angle
Inside Diameter: .375
Length: 3.05
Drop Length: .43
Weight
0.2300
Compatibility
Alternative Part Numbers
- Aeroquip 1AA6FJA6
- Aeroquip FJ9127-0606S
- Caterpillar 124-1980
- Dayco 108570
- Dayco 151570
- Goodyear 13420-0606
- Goodyear 14420-0606
- Goodyear B2-JCFX45-0606
- Goodyear T8-JCFX45-0606
- Goodyear UC-JCFX45-0606
- Hydraulink S64-0906
- Kurt Hydraulics FJX45-06-06
- NAPA G25175-0606
- Parker 13743-06-06
- Parker 13743-6-6
- Parker 137HY-6-6
- Parker 1L743-06-06
- Weatherhead 06E686
- Weatherhead 06EE686
- Weatherhead 06U686
- Weatherhead 06Z686
- Weatherhead 33606E-686
- Weatherhead 33606E686
