Hydraulic Coupling / Adapter - G25170-1012

Hydraulic Coupling / Adapter

Gates Hydraulic Coupling / Adapter G25170-1012 is engineered for superior performance in a wide range of hydraulic applications, offering both reliability and ease of use. This hydraulic coupling ensures a secure, leak-proof connection, making it an essential component for any hydraulic system. Designed with durability in mind, this hydraulic adapter effectively supports high-pressure environments, ensuring smooth fluid flow and efficient system operation. The hydraulic adapters in this series are built to withstand wear and tear, providing long-lasting service in demanding conditions. Whether you're upgrading your existing system or replacing a worn-out part, the Gates Hydraulic Coupling / Adapter G25170-1012 guarantees a top-tier connection every time. This hydraulic coupling is a trusted solution for maintaining optimal hydraulic performance, making it a must-have for any industrial setup.

Gates Corporation MegaCrimp Part No: G25170-1012

$26.37

Specifications

The patented "C" insert pre-assembled MegaCrimp coupling gives world-class, leak-proof performance. It is designed with a patented "C" insert attached to the ferrule that accommodates hose of different constructions and wall thicknesses. The insert's design ensures crimping forces are evenly distributed to form a concentric seal. The "C" insert simplifies inventory requirements since one MegaCrimp coupling size can accommodate various hose outside diameters, on both one- and two-wire braid hydraulic hose.

Female JIC 37 Flare Swivel (MegaCrimp)

Weight

0.4700

Gender:Female
Swivel:Yes
Thread Size:1 1/16-12
Seal Type:Mated Angle
Inside Diameter:.625
Length:3.2

Compatibility

Alternative Part Numbers

Dayco 108081
Aeroquip 1AA12FJ10
Aeroquip FJ9122-1210S
Caterpillar 124-1966
Goodyear 14400-1012
Goodyear B2-JCFX-1012
Kurt Hydraulics FJX-10-12
NAPA G25170-1012
Parker 10643-12-10
Parker 106HY-12-10
Weatherhead 10M612
Weatherhead 10U612
Weatherhead 10Z612
Parker 14400-1012
