Hydraulic Coupling / Adapter - G25170-0606

Hydraulic Coupling / Adapter

Female JIC 37 Flare Swivel (MegaCrimp)

Gates Corporation MegaCrimp Part No: G25170-0606

$9.82

Specifications

The patented "C" insert pre-assembled MegaCrimp coupling gives world-class, leak-proof performance. It is designed with a patented "C" insert attached to the ferrule that accommodates hose of different constructions and wall thicknesses. The insert's design ensures crimping forces are evenly distributed to form a concentric seal. The "C" insert simplifies inventory requirements since one MegaCrimp coupling size can accommodate various hose outside diameters, on both one- and two-wire braid hydraulic hose.

Weight

0.1900

Gender: Female
Swivel: Yes
Thread Size: 9/16-18
Seal Type: Mated Angle
Inside Diameter: .375
Length: 2.42

Compatibility

Alternative Part Numbers

OEM: Gates G25170-0606
Gates 6G-6FJX

Aeroquip 1AA6FJ6
Aeroquip 1GA6FJ6
Caterpillar 124-1956
Dayco 108071
Dayco 108071BK
Dayco 108082
Dayco 108495
Dayco 151071
Goodyear 13400-0606
Goodyear 14400-0606
Goodyear 32400-0606
Goodyear B2-JCFX-0606
Goodyear T8-JCFX-0606
Hydraulink S05H-0906
Kurt Hydraulics FJX-06-06
NAPA G25170-0606
Parker 10643-06-06
Parker 10643-6-6
Parker 106HY-6-6
Weatherhead 06E606
Weatherhead 06EE606
Weatherhead 06M606
Weatherhead 06S606
Weatherhead 06U606
Weatherhead 06Z606
Weatherhead 33606E-606
Weatherhead 33606E606
