Specifications

The patented "C" insert pre-assembled MegaCrimp coupling gives world-class, leak-proof performance. It is designed with a patented "C" insert attached to the ferrule that accommodates hose of different constructions and wall thicknesses. The insert's design ensures crimping forces are evenly distributed to form a concentric seal. The "C" insert simplifies inventory requirements since one MegaCrimp coupling size can accommodate various hose outside diameters, on both one- and two-wire braid hydraulic hose. SAE J1926/3 ISO 11926-3 Light-Duty (L Series) Stud End.
  • Male O-Ring Boss (MegaCrimp)
Weight
0.1700
Gender:Male
Swivel:No
Thread Size:9/16-18
Seal Type:O-Ring
Inside Diameter:.375
Length:2.2

Compatibility


Alternative Part Numbers

Dayco 108280
Dayco 151100
Aeroquip 1AA6MB6
Aeroquip FJ9124-0606S
Caterpillar 124-1929
Goodyear 13670-0606
Goodyear 14670-0606
Goodyear B2-OBM-0606
Goodyear T8-OBM-0606
Goodyear UC-OBM-0606
Kurt Hydraulics MB-06-06
NAPA G25120-0606
Parker 10543-06-06
Parker 10543-6-6
Parker 105HY-6-6
Weatherhead 06U44T
Weatherhead 06UP06
Weatherhead 06ZP06
Weatherhead 33606EP06
Weatherhead 33606E-P06
