Meritor Relay Valve 2 Port Part No: RSL110197

$95.88

The Meritor RSL110197 Relay Valve 2 Port is engineered to improve air brake system response in commercial vehicles. By rapidly directing air pressure from the reservoir to the brake chambers, it enhances braking efficiency and system performance. Built for durability and consistent operation, this relay valve supports heavy-duty applications across truck and trailer platforms. Ideal for fleet maintenance and replacement needs, the RSL110197 provides dependable brake control and long service life. Available at Wofford Truck Parts.

Specifications

The Meritor RSL110197 Relay Valve 2 Port is a vital component in heavy-duty air brake systems, designed to deliver rapid air pressure distribution for improved braking response. This valve helps reduce brake lag by allowing direct reservoir air flow to the brake chambers when activated. Constructed to meet industry performance standards, it ensures consistent and balanced braking under demanding operating conditions. Suitable for both truck and trailer applications, the RSL110197 enhances safety, reliability, and overall brake system efficiency. Trust Wofford Truck Parts for quality Meritor brake system components.

Air Systems
Genuine Sealco Valve - Relay Valve

Weight: 2.90
Unit Pack: 1
Pallet Quantity: 24
UPC Code: 680502105955
Brand: Meritor
Marketing Group: Relay
OE Mfg.: Sealco
Delivery Ports (NPT): 3/8 in.
SAE J1860 Tag: RV040
Control Port (NPT): 3/8 in.
Repair Kit: RSL9125
Reservoir Port (NPT): 1/2 in.
Nominal Crack Pressure: 4.0 PSI
Notes: Non-ABS two port service valves in several configurations.
Mounting: Use 6002 or 6006 Nipple Aftermarket Extended Warranty - General: 2 Years from the manufacture date of the product
VMRS Code: 013-010-399

Weight

2.9

Compatibility

EQUIPMENT TYPE

MODEL NUMBER

SERIAL NUMBER

ENGINE NUMBER

Freightliner (Cascadia, M2 Business Class)

International (LT Series, HV Series)

Kenworth (T680, T880)

Mack (Granite, Pinnacle)

Peterbilt (389, 567, 579)

Volvo (VNL, VHD)

Western Star (4900, 5700)

Freightliner Cascadia (2007–2023)

Kenworth T680 (2013–2023)

Peterbilt 579 (2013–2023)

International LT Series (2017–2023)

Volvo VNL (2004–2023)

Mack Anthem (2018–2023)
