Engine Coolant Thermostat

Gates Accessory Drive Belt Tensioner Assembly 38506 is made to surpass rigorous OEM standards, ensuring exceptional durability and reliability. Featuring Double Row Bearings for superior load-bearing capacity and extended lifespan. This belt tensioner gates utilizes Labyrinth Seal technology to prevent internal contamination and enhance longevity. Ideal for 1996-2004 Kenworth T800 trucks with Caterpillar C12 Diesel engines, this gates belt tensioner assembly ensures optimal performance of fan, alternator, and hub components.

Gates Corporation Green Stripe Part No: 33576

$66.48

Specifications

Green Stripe Heavy-Duty Thermostats are designed to withstand noise, vibration, and harshness found under the hood on heavy-duty truck, bus, tractors and heavy equipment applications.

Weight

0.1000

Type: Heavy-Duty Thermostat
Material: Steel, Copper
Seal Type: O-Ring
Flange Thickness: .28
Height: 3.076
Start to Open Temperature: 160

Compatibility

Autocar:
ACL: 1988
Peterbilt:
389: 2008–2011
Sterling:
AT9500: 1999–2008
Universal Application:
Heavy-Duty Trucks/Buses/Tractors: Engines requiring 160°F (71°C) thermostat with 2.875" flange diameter

Alternative Part Numbers

OEM: GATES 33576
MOTORCRAFT RT-338
MOTORCRAFT RT-342
ACDELCO 12TH8B

ACDELCO 12TH8B
ALLIS CHALMERS 4631416
CARQUEST 32246
CARQUEST OR STANT 14536
CARQUEST PREMIUM CAPS AND STATS 14536
CARTER 26-2866
CARTER 26-2916
CATERPILLAR 2848264
CATERPILLAR 2W7133
CATERPILLAR 4L7615
CATERPILLAR 4N2212
CATERPILLAR 4W4011
CATERPILLAR 6L7291
CATERPILLAR 8N4935
CATERPILLAR 9N2894
CATERPILLAR 9N3017
CATERPILLAR 9S9160
CST 4506
CUMMINS 135675
CUMMINS 146076
CUMMINS 194245
CUMMINS 204586
CUMMINS 3002742
CUMMINS Y201365
CUMMINS Y205566
DAYCO 83811
DELCO HARRISON 132-25
DELCO HARRISON 132-34
DOLE DV-236
DOLE DV-336
EDELLMANN 2063-160
FLEETRITE ZAM-2856
FLEETRITE ZAM-2906
GATES 33576
GATES 5776
GATES 5806
GENERAL MOTORS 12302405
GENERAL MOTORS 12302513
GENERAL MOTORS 5102112
GENERAL MOTORS 5118264
HERCULES 6409409
IDEAL TRIDON 31776
IDEAL TRIDON 31806
IDEAL TRIDON 32246
INTERNATIONAL HARVESTER (IHC) 276336R91
MACK 215SB165P1
MACK 657GC39P55
MOTORAD 8800
MOTORAD 880060
MOTORCRAFT RT-338
MOTORCRAFT RT-342
MURPHY MD19366
MURRAY TEMPERATURE CONTROL 277296
NAPA 613060
NAPA BELTS/HOSE 33576
PARTS MASTER 32506
REO TRUCKS 767A5
REO 767A5
ROBERTSHAW 450-160
ROBERTSHAW 451-160
SCOVILLE VD111800-2
SCOVILLE VD111800-2W
STANDARD THOMSON 356-160
STANDARD THOMSON 359-160
STANT 14536
STANT 32506
STANT S-450-160
WALTHAM W356-160
WALTHAM W359-160
WAUCHOPE 152154
WAUCHOPE 153154
WAUCHOPE 153154B
WAUCHOPE 153154C
WAUCHOPE 153154E
WAUCHOPE 176823
WAUCHOPE 199221D
WAUCHOPE 199221E
WAXSTAT WT/8
WHITE 027074996
WHITE 063837
WHITE 491417
WHITE A010681
